TELEGÄRTNER STX V1 surface-mounted box, RJ45 module A Cat.6A (ISO/IEC)

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

In stock - available for delivery within a few days

Ordered by 2 p.m. - usually shipped the same day

Item no.	25168707
Brand / Manufacturer	TELEGÄRTNER
Manuf. item no.	100007446
EAN	4018359353926
Item weight	0.085 kg

Description

storage of cables with diameter 5...10 mm
simple mounting of bulkheads through a central screwed gland or four screws
NBR aiguilette at the protection cap
bay for marking labels
with bend protection to prevent cables from being excessively bent
rugged zinc diecast or plastic housing
protection class IP67
Variant 1 acc. to IEC 61076-3-106
pre-assembled plugs and set products for simple assembly
available with RJ45 Cat.6A, Cat.6 Class EA, USB or FO insert

Specifications

Manufacturer	TELEGÄRTNER
Product group	Connection technology TP
Product type	Connectors RJ-45
Colour	black
Transfer quality	Cat6A / Class EA
Material (casing)	PA UL94 V0
Protection class (IP Code)	IP67
Dimensions (HxWxD)	65,5 x 64 x 78 mm
Operating temperature min.	-40 °C
Operating temperature max.	85 °C
Height	65.5 mm
Width	64 mm
Depth	78 mm
Weight	86 g
Height of packaging (single piece)	80 mm
Width of packaging (single piece)	100 mm
Depth of packaging (single piece)	180 mm
Package weight (single piece)	0.085 kg
