BACHMANN 19 inch 1U BN2000 6xCEE7/3, TCP/IP power 2.0m CEE7/7

BACHMANN 19 inch 1U BN2000 6xCEE7/3, TCP/IP power 2.0m CEE7/7

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
Deliverable approx. 12/05/2024
Item no. 19070892
Brand / Manufacturer BACHMANN
Manuf. item no. 329.3009
EAN 4016514048366
Item weight 1.068 kg

Description

19-inch 1U BN2000 6xCEE7/3 TCP/IP power 2.0m CEE7/7

BN2000 6x socket outlets with earthing contact Integrated function for measuring current, voltage, reactive power, apparent power, active power, energy, frequency and power factor Integrated temperature sensor + two interfaces for external sensors with integrated display Integrated web server with 10/100Mbit Ethernet connection 2.0m H05VV-F 3G1.5mm² with earthing contact angle plug incl. mounting bracket and screws packed in BlueNet box 2.0m H05VV-F 3G1.5mm² with earthing contact angle plug

Specifications

Manufacturer BACHMANN
Product group Power Bars
Product type Power supply
Colour black /silver
Length 2 m
Number of socket pots 6
Socket type 3P. German, CEE 7/3, Type-F
Plug type 3P. German, CEE 7/7, Type-E/F
Regional use Germany, Austria, Netherlands
Height 0.1 m
Width 0.04 m
Depth 0.44 m
Weight 1.03 kg
Height of packaging (single piece) 110 mm
Width of packaging (single piece) 90 mm
Depth of packaging (single piece) 530 mm
Package weight (single piece) 1.068 kg

Downloads

Manufacturer data sheet - Deutsch (529.5 KB)

Download

Manufacturer data sheet - English (529.5 KB)

Download

More PDF data - Installation and safety instructions - German - English - French - Italian (482.4 KB)

Download

The BACHMANN brand stands for customer-oriented electrotechnical components and systems.

In the development and manufacture of the products, emphasis is also placed on future topics such as energy management and energy efficiency for data centers and industry as well as building installation systems. The company benefits from almost 70 years of experience in the electronics industry.
