D-Link DXS-1210-12SC 10G SFP+ Switch 12-Port Smart Managed 2x Combo

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Deliverable approx. 12/06/2024

Item no.	21182280
Brand / Manufacturer	D-LINK
Manuf. item no.	DXS-1210-12SC/E
EAN	790069467646
Item weight	3.854 kg

Description

10 Gigabit Ethernet Smart Managed Switch

12-Port Smart Managed 10G SFP+ Switch 2x Combo, dlink|green 3.0, 10x 1000M/10Gbit/s SFP+ Slot, 2x 100/1000/10Gbit/s TP und 1000/10Gbit/s SFP+ Combo-Port, 1x RJ-45 RS232 Console Port, 802.3x Flow Control, 802.3ad Link Aggregation und statische Trunks, bis zu 8 Ports in bis zu 8 Gruppen, Jumbo Frames bis 9KB, 16K MAC-Adressen, 802.3az Energy Efficient Ethernet (EEE) Port-Stromsparmodus im Leerlauf, automatische Verringerung der Signalstärke abhängig von der Kabellänge, automatisches und zeitplangesteuertes Umschalten in den Stromsparmodus von ungenutzen Anschlüssen, automatische Abschaltung von Ports und LEDs nach Zeitplan, automatischer System Stromsparmodus nach Zeitplan, reduzierter Stromverbrauch, geringere Hitzeentwicklung, längere Lebensdauer, geringere Betriebskosten, 802.1D und 802.1w Rapid Spanning Tree, Loopback Detection, ERPS-Unterstützung, 802.1Q VLAN Unterstützung mit bis zu 4K statischen Gruppen, automatisches Voice- und Surveillance-VLAN,

Gast-VLAN, Traffic Segmentation, 802.1p port-basierte Prioritätssteuerung mit 8 Queues, IGMP Snooping v1/2/3 und MLD Snooping v1/2, 802.1x Port-basierte Zugangskontrolle (RADIUS), max. 64 (IPv4/IPv6) statische Routen und Default Route, Bandbreitenmanagement, ACL mit bis zu 256 Regeln, bis zu 1K statische MAC-Adressen, D-Link Safeguard Engine, Broadcast Storm Control, Port Security, DHCP Server Screening, DoS Attack Prevention, Web-basiertes Management, D-Link Network Assistant Programm (DNA), CLI, TELNET, SNMPv1/2c/3, SSL, IPv6 Ready, Port Mirroring, Kabeldiagnose, Firmware Release 1.15 nicht abwärtskompatibel zu Hardware A1, Betriebstemperatur -5 bis 50°C, 2x Smart Lüfter

10x 10G-SFP+ Port
2x kombinierter 100/1000/2.5G/5G/10GBASE-T/SFP+ Port
Switchkapazität 240 Gbit/s

Specifications

Manufacturer	D-LINK
Product group	Netzwerkkomponenten
Product type	Gigabit Ethernet Switch
Colour	black
Network standard	10 Gigabit Ethernet
LAN (Mbps)	10000
Quantity of ports	12
10 Gigabit Ethernet Ports Fibre	12
Power over Ethernet (PoE)	nein
Dimensions (HxWxD)	440 x 210 x 44 mm
Mains connection	Kaltgeräte-Anschluss
Operating temperature min.	-5 °C
Operating temperature max.	50 °C
Height	44 mm
Width	440 mm
Depth	210 mm
Weight	2.73 kg
Height of packaging (single piece)	90 mm
Width of packaging (single piece)	360 mm
Depth of packaging (single piece)	550 mm
Package weight (single piece)	3.854 kg

Downloads

Manufacturer data sheet - English (487.6 KB)

Download
