Manufacturer	D-LINK
Product group	Netzwerk-Switches
Product type	Gigabit Ethernet Switch
Colour	black
Network standard	10 Gigabit Ethernet
LAN (Mbps)	10000
Quantity of ports	24
10 Gigabit Ethernet Ports RJ-45	20
Free slots for SFPs	4
Mains connection	Kaltgeräte-Anschluss
Height	44 mm
Width	441 mm
Depth	380 mm
Weight	7609.6 g
Height of packaging (single piece)	190 mm
Width of packaging (single piece)	550 mm
Depth of packaging (single piece)	600 mm
Package weight (single piece)	10.522 kg

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity	20
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity	4
Console port	RJ-45
Copper ethernet cabling technology	10BASE-T,10GBASE-T,100BASE-T,1000BASE-T
USB 2.0 ports quantity	1

Weight & dimensions

Width	441 mm
Depth	380 mm
Height	44 mm
Weight	6.65 kg

Power

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	2 A
Power consumption (max)	159.8 W

Operational conditions

Operating temperature (T-T)	-5 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 95%
Storage relative humidity (H-H)	5 - 95%
Heat dissipation	557.94 BTU/h

Networking

Networking standards	IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1Qau,IEEE 802.1Qaz,IEEE 802.1Qbb,IEEE 802.1s,IEEE 802.1v,IEEE 802.1w,IEEE 802.1x,IEEE 802.3x
10G support	Y
Full duplex	Y
Head-of-line (HOL) blocking	Y
Flow control support	Y
Port mirroring	Y
Link aggregation	Y
Spanning tree protocol	Y

Data transmission

MAC address table	48000 entries
Switching capacity	480 Gbit/s
Forwarding rate	357.12 Mpps
Number of queues	8
Jumbo frames support	Y
Jumbo frames	12000

Security

Access Control List (ACL)	Y
DHCP client	Y
DHCP server	Y
Security algorithms	802.1x RADIUS
SSH/SSL support	Y
IGMP snooping	Y
Loop protection	Y
BPDU filtering/protection	Y
Authentication	Guest VLAN,MAC-based authentication,Port-based authentication

Management features

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Y
System event log	Y
MIB support	RFC1065, RFC1066, RFC1155, RFC1156, RFC2578, RFC1212, RFC1213, RFC1215, RFC1493, RFC4188,RFC1157, RFC2571, RFC2572, RFC2573, RFC2574, RFC2575, RFC2576, RFC1157, RFC2571, RFC2572, RFC2573, RFC2574, RFC2575, RFC2576, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC3636, RFC271, RFC1757, RFC2819, RFC2021, RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC3635, RFC2668, RFC2674, RFC4363, RFC2863, RFC2618, RFC4022, RFC4113, RFC3298, RFC2620, RFC2925, RFC2465, RFC2466, RFC2737, RFC2787, RFC1724, RFC1850, RFC5132, RFC2932, RFC2934, RFC4292, RFC4293, RFC791, RFC768, RFC793, RFC792, RFC2463, RFC4443, RFC4884, RFC826, RFC1338, RFC1519, RFC2474, RFC3168, RFC3260, RFC1321, RFC2284, RFC2865, RFC2716, RFC1759, RFC3580, RFC3748, RFC2571, RFC2572, RFC2573, RFC2574, RFC3246, RFC3247, RFC1886, RFC1981, RFC2460, RFC2461, RFC4861, RFC2462, RFC4862, RFC2464, RFC2767, RFC3513, RFC4291, RFC2893, RFC4213, RFC3484, RFC2003, RFC1191, RFC5415
Web-based management	Y
ARP inspection	Y

Optical fiber

Fiber optic connector	SFP+

Design

Stackable	Y
Product colour	Black
Number of fans	3 fan(s)
Safety	cUL, CB, CE, CCC, BSMI
Electromagnetic compatibility	CE, FCC A, C-Tick, VCCI, BSMI, CCC

Power over Ethernet (PoE)

Power over Ethernet (PoE)	N

Performance

Physical stacking (units)	4
Virtual stacking (units)	32
Built-in processor	Y
Packet buffer memory	4 MB

Virtual LAN features

VLAN support	Y
Virtual LAN features	Private VLAN,Voice VLAN,MAC address-based VLAN,Port-based VLAN
Number of VLANs	4094

Multicast features

Multicast support	Y
Multicast Listener Discovery (MLD) snooping	MLD v1, MLD v2
