Intel Core i7-13700 processor 30 MB Smart Cache Box

Intel Core i7-13700 processor 30 MB Smart Cache Box

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
In stock - available for delivery within a few days
Item no. 527449498
Brand / Manufacturer INTEL
Manuf. item no. BX8071513700
EAN 5032037260213

Description

Intel Core i7-13700. Processor family: Intel® Core™ i7, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770, On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, On-board graphics card base frequency: 300 MHz. Market segment: Desktop, Use conditions: PC/Client/Tablet, Workstation, PCI Express slots version: 5.0, 4.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.2 GHz

Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Intel® Turbo Boost Max Technology 3.0
Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.

Specifications

Manufacturer INTEL
Product type Processors
Technical details
OpenCL version 3.0
Target market Gaming, Content Creation
Launch date Q1'23
Status Launched
Processor
Processor family Intel® Core™ i7
Processor cores 16
Processor socket LGA 1700
Box Yes
Cooler included Yes
Processor manufacturer Intel
Processor model i7-13700
Processor operating modes 64-bit
Processor generation 13th gen Intel® Core™ i7
Processor threads 24
Performance cores 8
Efficient cores 8
Processor boost frequency 5.2 GHz
Performance-core boost frequency 5.1 GHz
Performance-core base frequency 2.1 GHz
Efficient-core boost frequency 4.1 GHz
Efficient-core base frequency 1.5 GHz
Processor cache 30 MB
Processor cache type Smart Cache
Processor base power 65 W
Maximum turbo power 219 W
Bus type DMI4
Maximum number of DMI lanes 8
Memory bandwidth supported by processor (max) 89.6 GB/s
Processor codename Raptor Lake
Processor ARK ID 230490
Memory
Memory channels Dual-channel
Maximum internal memory supported by processor 192 GB
Memory types supported by processor DDR4-SDRAM, DDR5-SDRAM
ECC Yes
Non-ECC Yes
Memory bandwidth (max) 89.6 GB/s
Weight & dimensions
Processor package size 45 x 37.5 mm
Operational conditions
Tjunction 100 °C
Packaging data
Package type Retail box
Other features
L2 cache 24576 KB
Maximum internal memory 192 GB
Graphics output eDP 1.4b, DP 1.4a, HDMI 2.1
Graphics
On-board graphics card Yes
Discrete graphics card No
On-board graphics card model Intel UHD Graphics 770
Discrete graphics card model Not available
On-board graphics card outputs supported Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card base frequency 300 MHz
On-board graphics card dynamic frequency (max) 1600 MHz
Number of displays supported (on-board graphics) 4
On-board graphics card DirectX version 12.0
On-board graphics card OpenGL version 4.5
On-board graphics card maximum resolution (DisplayPort) 7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI) 4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI) 60 Hz
On-board graphics card ID 0xA780
Number of execution units 32
Multi-Format Codec Engines 2
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Intel® Turbo Boost Technology 2.0
Intel® Quick Sync Video Technology Yes
Intel® Clear Video HD Technology (Intel® CVT HD) Yes
Intel® AES New Instructions (Intel® AES-NI) Yes
Enhanced Intel SpeedStep Technology Yes
Intel Trusted Execution Technology Yes
Intel® Speed Shift Technology Yes
Intel® Turbo Boost Max Technology 3.0 frequency 5.2 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes
Intel® Control-flow Enforcement Technology (CET) Yes
Intel® Thread Director Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Intel® Secure Key Yes
Intel® Active Management Technology (Intel® AMT) Yes
Intel Stable Image Platform Program (SIPP) Yes
Intel® OS Guard Yes
Intel 64 Yes
Intel Virtualization Technology (VT-x) Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Turbo Boost Max Technology 3.0 Yes
Intel® Boot Guard Yes
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Volume Management Device (VMD) Yes
Mode-based Execute Control (MBE) Yes
Intel® vPro™ Platform Eligibility Yes
Intel® Standard Manageability (ISM) Yes
Intel® One-Click Recovery Yes
Intel® Remote Platform Erase (RPE) Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp) Yes
Intel vPro® Enterprise Platform Eligibility Yes
Intel® Threat Detection Technology (TDT) Yes
Intel® Hardware Shield Eligibility Yes
Intel® Total Memory Encryption - Multi Key Yes
Intel vPro® Essentials Platform Eligibility Yes
Features
Execute Disable Bit Yes
Idle States Yes
Thermal Monitoring Technologies Yes
Market segment Desktop
Use conditions PC/Client/Tablet, Workstation
Maximum number of PCI Express lanes 20
PCI Express slots version 5.0, 4.0
PCI Express configurations 1x16+1x4, 2x8+1x4
Supported instruction sets SSE4.1, SSE4.2, AVX 2.0
Scalability 1S
CPU configuration (max) 1
Embedded options available Yes
Direct Media Interface (DMI) Revision 4.0
Export Control Classification Number (ECCN) 5A992C
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Logistics data
Harmonized System (HS) code 8542310001
