Intel Core i9-14900 processor 36 MB Smart Cache Box
Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!
LoginDescription
Intel Core i9-14900. Processor family: Intel® Core™ i9, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770, On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, On-board graphics card base frequency: 300 MHz. Market segment: Desktop, Use conditions: Workstation, PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.6 GHz, Intel® Thermal Velocity Boost Frequency: 5.8 GHz
Specifications
Manufacturer | INTEL |
---|---|
Product type | Processors |
Technical details
OpenCL version | 3.0 |
---|---|
Launch date | Q1'24 |
Status | Launched |
Processor
Processor family | Intel® Core™ i9 |
---|---|
Processor cores | 24 |
Processor socket | LGA 1700 |
Box | Yes |
Cooler included | Yes |
Processor manufacturer | Intel |
Processor model | i9-14900 |
Processor operating modes | 64-bit |
Processor generation | Intel Core i9-14xxx |
Processor threads | 32 |
Performance cores | 8 |
Efficient cores | 16 |
Processor boost frequency | 5.8 GHz |
Performance-core boost frequency | 5.4 GHz |
Performance-core base frequency | 2 GHz |
Efficient-core boost frequency | 4.3 GHz |
Efficient-core base frequency | 1.5 GHz |
Processor cache | 36 MB |
Processor cache type | Smart Cache |
Processor base power | 65 W |
Maximum turbo power | 219 W |
Stepping | B0 |
Maximum number of DMI lanes | 8 |
Memory bandwidth supported by processor (max) | 89.6 GB/s |
Processor codename | Raptor Lake |
Processor ARK ID | 236793 |
Memory
Memory channels | Dual-channel |
---|---|
Maximum internal memory supported by processor | 192 GB |
Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
ECC | Yes |
Memory bandwidth (max) | 89.6 GB/s |
Weight & dimensions
Processor package size | 45 x 37.5 mm |
---|
Operational conditions
Tjunction | 100 °C |
---|
Other features
L2 cache | 32768 KB |
---|---|
Maximum internal memory | 192 GB |
Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
Graphics
On-board graphics card | Yes |
---|---|
Discrete graphics card | No |
On-board graphics card model | Intel UHD Graphics 770 |
Discrete graphics card model | Not available |
On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
On-board graphics card base frequency | 300 MHz |
On-board graphics card dynamic frequency (max) | 1650 MHz |
Number of displays supported (on-board graphics) | 4 |
On-board graphics card DirectX version | 12.0 |
On-board graphics card OpenGL version | 4.5 |
On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 5120 x 3200 pixels |
On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120 Hz |
On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
On-board graphics card ID | 0xA780 |
Number of execution units | 32 |
Multi-Format Codec Engines | 2 |
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
---|---|
Intel® Turbo Boost Technology | 2.0 |
Intel® Quick Sync Video Technology | Yes |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Thermal Velocity Boost | Yes |
Intel® Adaptive Boost Technology | Yes |
Intel® Turbo Boost Max Technology 3.0 frequency | 5.6 GHz |
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Yes |
Intel® Thermal Velocity Boost Frequency | 5.8 GHz |
Intel® Control-flow Enforcement Technology (CET) | Yes |
Intel® Thread Director | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel® Secure Key | Yes |
Intel® OS Guard | Yes |
Intel 64 | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Turbo Boost Max Technology 3.0 | Yes |
Intel® Boot Guard | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
Intel® Volume Management Device (VMD) | Yes |
Mode-based Execute Control (MBE) | Yes |
Intel® Standard Manageability (ISM) | Yes |
Features
Execute Disable Bit | Yes |
---|---|
Idle States | Yes |
Thermal Monitoring Technologies | Yes |
Market segment | Desktop |
Use conditions | Workstation, PC/Client/Tablet |
Maximum number of PCI Express lanes | 20 |
PCI Express slots version | 4.0, 5.0 |
PCI Express configurations | 1x16+1x4, 2x8+1x4 |
Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
Scalability | 1S |
CPU configuration (max) | 1 |
Embedded options available | Yes |
Direct Media Interface (DMI) Revision | 4.0 |
Export Control Classification Number (ECCN) | 5A992C |
Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
Logistics data
Harmonized System (HS) code | 8542310001 |
---|
