Intel Core i9-14900KF processor 36 MB Smart Cache

Intel Core i9-14900KF processor 36 MB Smart Cache

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
In stock - available for delivery within a few days
Item no. 528347035
Brand / Manufacturer INTEL
Manuf. item no. CM8071505094018
EAN 5056489771264

Description

Intel Core i9-14900KF. Processor family: Intel® Core™ i9, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.8 GHz, Intel® Thermal Velocity Boost Frequency: 6 GHz. Processor package size: 45 x 37.5 mm

Specifications

Manufacturer INTEL
Product type Processors
Technical details
Launch date Q4'23
Status Launched
Processor
Processor family Intel® Core™ i9
Processor cores 24
Processor socket LGA 1700
Box No
Processor manufacturer Intel
Processor model i9-14900KF
Processor operating modes 64-bit
Processor generation Intel Core i9-14xxx
Processor threads 32
Performance cores 8
Efficient cores 16
Processor boost frequency 6 GHz
Performance-core boost frequency 5.6 GHz
Performance-core base frequency 3.2 GHz
Efficient-core boost frequency 4.4 GHz
Efficient-core base frequency 2.4 GHz
Processor cache 36 MB
Processor cache type Smart Cache
Processor base power 125 W
Maximum turbo power 253 W
Stepping B0
Maximum number of DMI lanes 8
Memory bandwidth supported by processor (max) 89.6 GB/s
Processor codename Raptor Lake
Processor ARK ID 236787
Memory
Memory channels Dual-channel
Maximum internal memory supported by processor 192 GB
Memory types supported by processor DDR4-SDRAM, DDR5-SDRAM
Memory bandwidth (max) 89.6 GB/s
Weight & dimensions
Processor package size 45 x 37.5 mm
Operational conditions
Tjunction 100 °C
Other features
L2 cache 32768 KB
Maximum internal memory 192 GB
Graphics
On-board graphics card No
Discrete graphics card No
On-board graphics card model Not available
Discrete graphics card model Not available
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Intel® Turbo Boost Technology 2.0
Intel® AES New Instructions (Intel® AES-NI) Yes
Enhanced Intel SpeedStep Technology Yes
Intel® Speed Shift Technology Yes
Intel® Thermal Velocity Boost Yes
Intel® Adaptive Boost Technology Yes
Intel® Turbo Boost Max Technology 3.0 frequency 5.8 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes
Intel® Thermal Velocity Boost Frequency 6 GHz
Intel® Control-flow Enforcement Technology (CET) Yes
Intel® Thread Director Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Intel® Secure Key Yes
Intel® OS Guard Yes
Intel 64 Yes
Intel Virtualization Technology (VT-x) Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Turbo Boost Max Technology 3.0 Yes
Intel® Boot Guard Yes
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Volume Management Device (VMD) Yes
Mode-based Execute Control (MBE) Yes
Intel® Standard Manageability (ISM) Yes
Features
Execute Disable Bit Yes
Idle States Yes
Thermal Monitoring Technologies Yes
Market segment Desktop
Use conditions PC/Client/Tablet
Maximum number of PCI Express lanes 20
PCI Express slots version 4.0, 5.0
PCI Express configurations 1x16+1x4, 2x8+1x4
Supported instruction sets AVX 2.0, SSE4.1, SSE4.2
Scalability 1S
CPU configuration (max) 1
Embedded options available No
Thermal solution specification PCG 2020A
Direct Media Interface (DMI) Revision 4.0
Export Control Classification Number (ECCN) 5A992C
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Logistics data
Harmonized System (HS) code 8542310001
