Manufacturer	INTEL
Product type	Processors

Technical details

Package carrier	E1B
Launch date	Q4'23
Status	Launched
Number of UPI links	2
Servicing status	Baseline Servicing

Processor

Processor family	Intel Xeon Silver
Processor cores	16
Processor socket	FCLGA4677
Box	Yes
Processor manufacturer	Intel
Processor model	4514Y
Processor base frequency	2 GHz
Processor operating modes	64-bit
Processor generation	Intel Xeon Scalable 5th Gen
Processor threads	32
Intel® UPI Speed	16 GT/s
Processor boost frequency	3.4 GHz
Processor cache	30 MB
Thermal Design Power (TDP)	150 W
Stepping	R1
Processor ARK ID	237557

Memory

Memory channels	Octa-channel
Maximum internal memory supported by processor	4 TB
Memory types supported by processor	DDR5-SDRAM
ECC	Yes

Weight & dimensions

Processor package size	77.5 x 56.5 mm

Operational conditions

Tcase	79 °C
DTS Max	90 °C

Other features

Maximum internal memory	4 TB

Graphics

On-board graphics card	No
Discrete graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available

Processor special features

Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	2.0
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel Trusted Execution Technology	Yes
Intel® Speed Shift Technology	Yes
Intel® Transactional Synchronization Extensions	Yes
Intel® Total Memory Encryption	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Crypto Acceleration	Yes
Intel® Platform Firmware Resilience Support	Yes
Maximum Enclave Size Support for Intel® SGX	64 GB
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® OS Guard	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel 64	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
AVX-512 Fused Multiply-Add (FMA) units	2
Intel® Boot Guard	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® Resource Director Technology (Intel® RDT)	Yes
Intel® Volume Management Device (VMD)	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Total Memory Encryption - Multi Key	Yes
Intel® QuickAssist Software Acceleration	Yes
Intel® On Demand Feature Activation	Yes
Intel® Data Streaming Accelerator (DSA)	1 default devices
Intel® Advanced Matrix Extensions (AMX)	Yes
Intel® Speed Select Technology – Core Power	Yes

Features

Execute Disable Bit	Yes
Market segment	Server
Use conditions	Server/Enterprise
Maximum number of PCI Express lanes	80
PCI Express slots version	5.0
Supported instruction sets	AMX, AVX, AVX 2.0, AVX-512, SSE4.2
Scalability	2S
Embedded options available	Yes
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	740.17B1

Logistics data

Harmonized System (HS) code	8542310001
