ROLINE Cat.6 (Class E) Keystone Jack SLIM, RJ-45, UTP, tool-free, black

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

In stock - available for delivery within a few days

Ordered by 2 p.m. - usually shipped the same day

Item no.	26110375
Brand / Manufacturer	ROLINE
Manuf. item no.	26.11.0375
EAN	7611990110971
Item weight	0.04 kg

Description

The system is composed of a 19" patch panel frame and the UTP Cat.6 RJ-45 keystone jacks
Assembling of cables and keystones takes place toolless
Colour code on the keystone jacks, based on the standard EIA/TIA 568 A and 568 B
Colour: Black

For a structured unshielded Cat.6 cabling system we recommend to use the following components:

ROLINE Cat.6 UTP Cable, Solid Wire, AWG23: 21.15.0990 (100 m), 21.15.0991 (300 m)
Flush Mount Wall Jack for Keystones, unloaded: 25.16.8579
ROLINE Cat.6 Keystone, RJ-45, unshielded: 26.11.0352 (black), 26.11.0353 (white)
19" Keystone Patch Panel, 24 Ports, unshielded: 26.11.0356 (light grey), 26.11.0357 (black)
ROLINE Cat.6 UTP Patch Cord, grey, 5 m: 21.15.0935

Our in-house laboratory has tested this cable-plug combination, in a Channel of 100 meters, in compliance with Class E specifications.

Specifications

Manufacturer	ROLINE
Product group	Connection technology TP
Product type	RJ45 Keystone Jack
Colour	black
Shield type	Not screened
Transfer quality	Cat6 / Class E
Quantity of ports	24
Assembly cable connection	Krone LSAplus
Assignment	EIA/TIA 568A & 568B
Modular assembly	yes
Connection direction	Straight
Height	21 mm
Width	12 mm
Depth	36 mm
Weight	6.4 g
Height of packaging (single piece)	20 mm
Width of packaging (single piece)	30 mm
Depth of packaging (single piece)	50 mm
Package weight (single piece)	0.04 kg
