:strip_icc():strip_exif()/bilder/s21/21159280_2023_m_0_hi.jpg "ROLINE Fibre Optic Jumper Cable, 50/125 µm, LC/LC, OM5, Low-Loss Connector, green, 20 m")
:strip_icc():strip_exif()/bilder/s21/21159280_2000_p_0_lo.jpg "ROLINE Fibre Optic Jumper Cable, 50/125 µm, LC/LC, OM5, Low-Loss Connector, green, 20 m")
ROLINE Fibre Optic Jumper Cable, 50/125 µm, LC/LC, OM5, Low-Loss Connector, green, 20 m
Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!
Login| Item no. | 21159288 |
|---|---|
| Brand / Manufacturer | ROLINE |
| Manuf. item no. | 21.15.9288 |
| EAN | 7630049628571 |
| Item weight | 0.19 kg |
:strip_icc():strip_exif()/bilder/icons/icon_lsoh.png){kind=icon}
|
|
| Colour | |
| Length | |
:strip_icc():strip_exif()/logos/roline.png "ROLINE")
Description
ROLINE fiber optic patch cables in OM5 quality for high-performance fiber optic cabling in high-density environments.
- Security for the future! The OM5 fiber connector quality with very low insertion ensures an excellent quality at very high bandwidths of up to 100 Gbit/s Ethernet, Fibre Channel, and OIF applications with up to 150 meters - extends the system cost benefits to ultra long building backbones and medium length campus backbones.
- Material and clothing in ROLINE quality
- Duplex cables with fiber type Multimode 50/125µm, OM5
- The cable assembled with "low-loss" connectors achieve very good values for insertion loss and reflection. In comparison:
- Typical attenuation of a low-loss LC connector: 0.15 dB
- Attenuation 850nm ≤ 2.3 dB/km, 953nm ≤ 1.7 dB/km, 1300nm ≤ 0.6 dB/km
- IL (Insertion Loss) < 0.15dB
- RL (Return Loss) >= 30dB
- The cable assembled with "low-loss" connectors achieve very good values for insertion loss and reflection. Insertion loss of less than 0.15dB
- Outer diameter: 2.0mm
- UPC polish
- Modal Bandwidth: 4700 MHz-km (this bandwidth is based on application-specific implementation of the EMBC requirements)
Specifications
| Manufacturer | ROLINE |
|---|---|
| Product group | Fibre optic cable |
| Product type | Fibre Optic Jumper Cables OM5 |
| Colour | green |
| Length | 20 m |
| Quantity of fibre | 2 |
| Conductor composition | Compact conductor |
| Cable type | Duplex Cable |
| External cable | no |
| Fibre section | Multi mode 50/125µm OM5 |
| Connection ports | LC / LC |
| Side 1 Connector Type | LC |
| side 1 connector ferrules | weinig verlies |
| Side 2 Connector Type | LC |
| side 2 connector ferrules | weinig verlies |
| Min. Bending radius, static | 20 mm |
| Min. Bending radius, dynamic | 40 mm |
| Colour (Cable) | Lime Green |
| Aramid strain relief | yes |
| External cable diameter | 2 mm |
| Mantle of external cable | LS0H |
| Cable LSOH | yes |
| Flame retardant according to IEC 60332-1-2 | yes |
| Low smoke according to IEC 61034-2 | yes |
| Halogen free according to IEC 60754-2 | yes |
| Max. insertion loss | 0.15 dB |
| Min. return loss | 30 dB |
| Weight | 143.2 g |
| Height of packaging (single piece) | 10 mm |
| Width of packaging (single piece) | 180 mm |
| Depth of packaging (single piece) | 180 mm |
| Package weight (single piece) | 0.19 kg |
