ROLINE Industrial Switch, 6x RJ-45, 2x ST, unmanaged

ROLINE Industrial Switch, 6x RJ-45, 2x ST, unmanaged

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
In stock - available for delivery within a few days
Ordered by 2 p.m. - usually shipped the same day
Item no. 21131153
Brand / Manufacturer ROLINE
Manuf. item no. 21.13.1153
EAN 7611990176717
Item weight 0.65 kg

Description

Network-Switch for use in a industrial environment

  • Fast Ethernet switch with 6x 10/100Base-T ports and 2x 100Base-FX ports
  • Wide operating temperature range for use in a temperature critical environment
  • Support DIN rail mounting
  • Industrial-rated Emission and Immunity performance
  • Provides wire speed store-and-forward switching
  • Supports IEEE 802.3x flow control for full-duplex operation
  • Supports Back-pressure flow control for half-duplex operation
  • Power: Input: 7-30V DC, Consumption: 6.5W (max.)
  • Operating Temperature: - 20 °C - +70 °C
  • DC Input via terminal block or DC power jack (6.3mm/2.0mm)
  • As power supply we recommend using 21.13.1226

Specifications

Manufacturer ROLINE
Product group Network Switches
Product type Fast Ethernet Switch
Colour black
Network standard Fast Ethernet
LAN (Mbps) 10/100
Quantity of ports 8
Fast Ethernet Ports RJ-45 6
Fast Ethernet Ports Fibre 2
Mounting form DIN Rail
Management no
Stackable no
Dimensions (HxWxD) 106 x 40 x 140 mm
Power supply unit (internal/external) External
Mains connection Loose cable / screw terminals
Operating temperature min. -20 °C
Operating temperature max. 70 °C
Height 106 mm
Width 40 mm
Depth 140 mm
Weight 552.1 g
Height of packaging (single piece) 70 mm
Width of packaging (single piece) 150 mm
Depth of packaging (single piece) 210 mm
Package weight (single piece) 0.65 kg
