Synology DiskStation DS620SLIM NAS/storage server Desktop Ethernet LAN Black J3355
Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!
Login| Item no. | 522218336 |
|---|---|
| Brand / Manufacturer | SYNOLOGY |
| Manuf. item no. | DS620SLIM |
| EAN | 4711174723164 |
:strip_icc():strip_exif()/logos/synology.png "SYNOLOGY")
Description
Synology DiskStation DS620SLIM. Total installed storage capacity: 108 TB, Supported storage drive types: HDD & SSD, Storage drive capacity: 3000 GB. Processor family: Intel® Celeron®, Processor manufacturer: Intel, Processor model: J3355. Internal memory: 2 GB, Internal memory type: DDR3L, Maximum RAM supported: 6 GB. Ethernet LAN data rates: 10,100,1000 Mbit/s, Supported network protocols: CIFS, AFP, NFS, FTP, WebDAV. On-board graphics card base frequency: 250 MHz, On-board graphics card burst frequency: 700 MHz, Maximum on-board graphics card memory: 8 GB
Mini Private Server Combining Performance and StyleDS620slim is a mini 6-bay NAS with a stylish chassis design, perfectly blending in modern workplaces or apartments. Supporting near-instantaneous snapshot technology and real-time 4K video transcoding, DS620slim is an all-around file management solution that fulfills professionals’ needs of advanced data protection and high-quality media streaming.Remain classic while shrinking footprintThe mini 6-bay design keeps DS620slim classic and saves deployment space. With six 2.5" drive support, DS620slim is able to boost performance by installing SSDs.Compact DesignMini design with the dimensions of 121 x 151 x 175 mm, flexible to fit in anywhereRAID FlexibilityFlexible in a variety of RAID configurations to realize maximum 30TB raw capacity or better data protection with RAID 5/6/10SSD Cache SupportFurther enhance storage performance with SSD read/write cache while still having abundant drive bays for data storageBtrfs: Next generation storage efficiencyBtrfs file system introduces the most advanced storage technologies to meet the management needs of modern large scale businesses: Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots File or folder level data restoration makes data recovery fast and flexible Automatic file self-healing detects and recovers corrupted files without user interventionLearn more about the benefits of using BtrfsUltimate file management and sharingFile Station is a web-based, fast and secure management tool built to allow easy, drag-and-drop operations without requiring any complex setup on Mac or PC. Advanced search and filtering tools allow for easy organization and file sharing. For complete compatibility, DS620slim supports the following protocols: AFP, FTP, iSCSI, NFS, SMB, and WebDAV.Synchronize files across your devicesCloud Station Suite provides real-time data synchronization across all your devices and other Synology NAS. "Intelliversioning" keeps the most important file versions to better utilize storage space.4K Multimedia ServerAccess and stream your 4K media content anytime and anywhere. DS620slim supports 4K H.264/H.265 online transcoding via Video Station and DS video, allowing 4K videos to be converted and played on the fly on other computers, smartphones, and media players that originally do not support Ultra HD formats.
Specifications
| Manufacturer | SYNOLOGY |
|---|---|
| Product type | NAS & Storage Servers |
Technical details
| Harmonized System (HS) code | 84714100 |
|---|
Processor
| Processor family | Intel® Celeron® |
|---|---|
| Processor manufacturer | Intel |
| Processor model | J3355 |
| Processor frequency | 2 GHz |
| Processor boost frequency | 2.5 GHz |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor cache | 2 MB |
| CPU configuration (max) | 1 |
| PCI Express configurations | 1x2+2x1, 4x1 |
| PCI Express slots version | 2.0 |
| Processor cache type | Smart Cache |
| Processor code | SR2Z8 |
| Processor codename | Apollo Lake |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor package size | 24 x 31 mm |
| Processor socket | BGA 1296 |
| Stepping | B1 |
| System bus rate | 5 GT/s |
| Tjunction | 105 °C |
| Thermal Design Power (TDP) | 10 W |
| On-board graphics card model | Intel® HD Graphics 500 |
| Maximum internal memory supported by processor | 8 GB |
| Conflict-Free processor | Y |
Memory
| Internal memory | 2 GB |
|---|---|
| Internal memory type | DDR3L |
| Maximum RAM supported | 6 GB |
| Memory slots | 2 |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 2 |
|---|---|
| USB port | Y |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| eSATA ports quantity | 2 |
Weight & dimensions
| Width | 20.3 mm |
|---|---|
| Depth | 22.6 mm |
| Height | 18.5 mm |
| Weight | 2.18 g |
| Package weight | 2.197 g |
Power
| Power supply location | Built-in |
|---|---|
| Power supply unit (PSU) capacity | 65 W |
| Number of power supply units | 1 |
| Power consumption (typical) | 34.88 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Operating temperature (T-T) | 5 - 40 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 5 - 95% |
Network
| Ethernet LAN | Y |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | N |
| iSCSI support | Y |
| Wake-on-LAN ready | Y |
| Supported network protocols | CIFS, AFP, NFS, FTP, WebDAV |
Storage
| Storage drives installed | N |
|---|---|
| Total installed storage capacity | 108 TB |
| Number of storage drives supported | 6 |
| Installed storage drive type | N |
| Supported storage drive types | HDD & SSD |
| Storage drive capacity | 3000 GB |
| Storage drive interface | Serial ATA |
| RAID support | Y |
| Storage drive size | 2.5" |
| Storage drive sizes supported | 2.5" |
| Maximum supported storage capacity | 108 TB |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Hot-swap drive bays | Y |
| Supported file systems | BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4 |
Software
| Operating system installed | DiskStation Manager |
|---|
Packaging content
| Cables included | AC, LAN (RJ-45) |
|---|---|
| Quick start guide | Y |
Other features
| Processor ARK ID | 95597 |
|---|
Design
| Chassis type | Desktop |
|---|---|
| Cooling type | Active |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| Fan diameter | 8 cm |
| LED indicators | Y |
| Country of origin | Taiwan |
Graphics
| On-board graphics card base frequency | 250 MHz |
|---|---|
| On-board graphics card burst frequency | 700 MHz |
| Maximum on-board graphics card memory | 8 GB |
| Number of displays supported (on-board graphics) | 3 |
Processor special features
| Embedded options available | Y |
|---|---|
| Enhanced Intel SpeedStep Technology | Y |
| Execute Disable Bit | Y |
| Idle States | Y |
| Intel 64 | Y |
| Intel Clear Video Technology | Y |
| Intel Enhanced Halt State | Y |
| Intel Identity Protection Technology version | 1.00 |
| Intel Rapid Storage Technology | N |
| Intel Secure Boot | Y |
| Intel Secure Boot Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Small Business Advantage (SBA) version | 0.00 |
| Intel Smart Connect Technology | N |
| Intel Smart Connect Technology version | 0.00 |
| Intel Smart Response Technology version | 0.00 |
| Intel Stable Image Platform Program (SIPP) | N |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Trusted Execution Technology | N |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel® Anti-Theft Technology (Intel® AT) | N |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Y |
| Intel® High Definition Audio (Intel® HD Audio) | Y |
| Intel® Hyper Threading Technology (Intel® HT Technology) | N |
| Intel® Identity Protection Technology (Intel® IPT) | Y |
| Intel® Insider™ | N |
| Intel® InTru™ 3D Technology | N |
| Intel® OS Guard | N |
| Intel® Quick Sync Video Technology | Y |
| Intel® Secure Key | Y |
| Intel® Small Business Advantage (Intel® SBA) | N |
| Intel® Smart Response Technology | N |
| Intel® Turbo Boost Technology | N |
| Intel® Wireless Display (Intel® WiDi) | N |
| Maximum number of PCI Express lanes | 6 |
| Number of execution units | 12 |
| Thermal Monitoring Technologies | Y |
| UART | Y |
| Memory types supported by processor | DDR3L, LPDDR3-SDRAM, LPDDR4-SDRAM |
Performance
| Type | NAS |
|---|---|
| Device class | Small & Medium Business |
| Backup function | Y |
| Multilingual support | Y |
| Number of users | 1000 user(s) |
| Noise level | 20.5 dB |
