TRENDnet TEG-10GBSR 10GBASE-LR SFP+, Multi-Mode LC (400M with DDM)

TRENDnet TEG-10GBSR 10GBASE-LR SFP+, Multi-Mode LC (400M with DDM)

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
In stock - available for delivery within a few days
Ordered by 2 p.m. - usually shipped the same day
Item no. 21221086
Brand / Manufacturer TRENDNET
Manuf. item no. TEG-10GBSR
EAN 710931140170
Item weight 0.068 kg
TRENDNET

Description

Im laufenden Betrieb austauschbarer SFP+ Transceiver - SFP+ MSA konform - Unterstützt Durchsatz bis zu 10,5 Gbit/s

Der im laufenden Betrieb austauschbare TEG-10GBSR von TRENDnet, ein 10GBASE-SR SFP+ Multi-Mode LC Modul, funktioniert mit einem MSAkompatiblen SFP+ Slot. Dieser multimodale Transceiver überbrückt Entfernungen bis zu 550 Meter (1,804 Fuß), enthält einen LC-Duplex-Steckverbinder und unterstützt bis zu 10,5 Gbit/s Netzwerkdurchsatzgeschwindigkeit. Über Digital Diagnostics Monitoring (DDM) werden wichtige Geräteparameter wie Übermittlungs-/Empfangsleistung, Temperatur und Spannung aufgezeichnet.

TRENDnet’s hot-pluggable TEG-10GBSR, 10GBASE-SR SFP+ Multi Mode LC Module, works with a MSA compliant SFP+ slot. This Multi Mode transceiver spans distances up to 550 meters (1,804 feet), comes with a LC duplex connector, and supports up to 10.5 Gbps networking throughput speeds. Digital Diagnostics Monitoring (DDM) captures critical device parameters such as transmit/receive power, temperature, and voltage. Hot-Pluggable SFP+ Hot-pluggable SFP+ transceiver works with a MSA compliant SFP+ slot Fiber Wavelength Compatible with Multi Mode 850 nm transmissions Fiber Distance Supports networking for distances up to 550 meters (1,804 feet) Fiber Port LC-type duplex connector DDM Support Digital Diagnostics Monitoring (DDM) captures critical device parameters such as transmit/receive power, temperature, and voltage Power Supply Single 3.3 volt power supply Operating Temperature Rated for an operating temperature range of 0 to 70 °C (32 to 158 °F) Standards Compliant with SFF-8431, SFF-8432, SFF-8472, FC-PI-4,10G FC, and IEEE802.3ae 10GBASE-SR

Specifications

Manufacturer TRENDNET
Product group Netzwerkkomponenten
Product type Netzwerk-Transceiver-Module
Colour grey
Scope of delivery TEG-10GBSR
Height 12 mm
Width 57 mm
Depth 15 mm
Weight 16.7 g
Height of packaging (single piece) 60 mm
Width of packaging (single piece) 80 mm
Depth of packaging (single piece) 130 mm
Package weight (single piece) 0.068 kg
Weight & dimensions
Width 14.8 mm
Depth 56.5 mm
Height 11.8 mm
Weight 22 g
Power
Power consumption (typical) 0.439 W
Operational conditions
Operating temperature (T-T) 0 - 70 °C
Operating relative humidity (H-H) 0 - 95%
Performance
SFP transceiver type Fiber optic
Maximum data transfer rate 10000 Mbit/s
Interface type SFP+
Multi-mode fiber (MMF) supported Y
SFP transceiver standard SR
Fiber optic connector LC
Maximum transfer distance 550 m
Wavelength 850 nm
Networking standards IEEE 802.3ae
Fiber ports quantity 1
Features
Hot-Plug support Y

Downloads

Manufacturer data sheet - Deutsch (509.7 KB)

Download

Manufacturer data sheet - English (400.3 KB)

Download

Manufacturer data sheet - Français (510.3 KB)

Download
