TRENDnet TI-M6024 industrielles DIN-Rail-Netzteil

TRENDnet TI-M6024 industrielles DIN-Rail-Netzteil

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
In stock - available for delivery within a few days
Ordered by 2 p.m. - usually shipped the same day
Item no. 21221194
Brand / Manufacturer TRENDNET
Manuf. item no. TI-M6024
EAN 710931160376
Item weight 0.301 kg

Description

DIN Rail Netzteil für Industrieanwendungen - Liefert bis zu 60 Watt Strom (24 V, 2,5 A) - Universeller AC-Eingang - Metallgehäuse

  • Netzteil für Industrieanwendungen mit integriertem DIN-Schienenhalter
  • Liefert bis zu 60 Watt Strom (24 V, 2,5 A)
  • Universeller AC-Eingang
  • Kurzschluss-/Überlast-/Überspannungsschutz
  • UL 508 zertifiziert
  • Burn-in-Test unter Volllast (100%)
  • Extremer -20 bis 70 °C Betriebstemperaturbereich

Das 60 W industrielle DIN-Rail-Netzteil mit Einfachausgang von TRENDnet, Modell TI-M6024 , liefert bis zu 60 Watt Strom an industrielle PoE-Ausrüstung wie zum Beispiel Switches, Netzwerkkameras und Wi-Fi Access Points. Dieses Netzteil bietet einen integrierten DIN-Schienenhalter und Überlastschutz.

TI-M6024 (Version v1.0R) - Industrial power supply with integrated DIN-rail mount - Provides up to 60 Watts of power (24 V, 2.5 A) - Universal AC input - Short circuit/overload/over voltage protection - UL 508 approved - 100% full load burn-in test - Extreme -20 to 70 °C (-4 to 158 °F) operating temperature range

Specifications

Manufacturer TRENDNET
Product group Netzwerkkomponenten
Product type Netzteile
Colour white
Max. PoE output power (total) 60 W
Mounting form Hutschiene
Dimensions (HxWxD) 40 x 100 x 90 mm
Operating temperature min. -20 °C
Operating temperature max. 70 °C
Height 40 mm
Width 100 mm
Depth 90 mm
Weight 0.3 kg
Height of packaging (single piece) 50 mm
Width of packaging (single piece) 110 mm
Depth of packaging (single piece) 120 mm
Package weight (single piece) 0.301 kg
Weight & dimensions
Width 40 mm
Depth 100 mm
Height 90 mm
Weight 300 g
Power
Total power 60 W
AC input voltage 100 - 240
AC input frequency 50 - 60
Input current 1.8
Operational conditions
Operating temperature (T-T) -20 - 70 °C
Operating relative humidity (H-H) 0 - 90%
Features
Product type Power supply
Colour of product Green, White
LED indicators Y
Power protection features Over voltage, Overload, Short circuit
Mean time between failures (MTBF) 2992000 h
Certification CE, UL 508, UL 60950-1, CB 60950-1, TUV EN60950-1, Class I, Div. 2 hazardous locations T4

Downloads

Manufacturer data sheet - Deutsch (1.3 MB)

Download

PDF data sheet - Trendnet TI-M6024 v1.0R Power supply network switch component - English (1.3 MB)

Download
